Unlock the future of gate access with the Nice Apollo 480L Keypad, your trusty sidekick for secure entry! This robust, weather-resistant keypad, nestled in its cast aluminum shell, handles up to 480 unique codes for seamless control, whether for your home or business. With smart features like timed relays, anti-passback, and a helpful courtesy light, it's designed to make your life a breeze. Plus, its non-volatile memory ensures your settings are safe and sound, even if the power takes a nap!
| Dimensions |
4.0" W x 5.5" H x 3.0" D |
| Voltage |
12-24 Volts AC or DC |
| Current |
10 mA typical, 150 mA maximum |
| Main Relay Capacity |
Form "C" 5 Amps @ 28 Volts maximum |
| Auxiliary Relay Capacity |
Form "C" 1 Amp @ 28 Volts maximum |
| Solid State Outputs |
Short-to-common 100 mA @ 24 VDC maximum |
| Operating Temperature |
-22° F to +149° F |
| Humidity |
5% to 95% non-condensing |
| Max User Codes |
480 |
| Code Length |
1 to 6 digits |
| Enclosure Material |
Rugged Cast Aluminum |
| Memory Type |
EEPROM (retains programming without power) |
