Reyee Enterprise Grade 8-Port Gigabit Layer 2 Cloud-Managed Switch – High-Performance Smart Network Infrastructure

The Reyee RG-NBS3300-8MG2XS-P delivers enterprise-grade speed, security, and scalability for demanding commercial and industrial environments. Featuring 8 Gigabit Ethernet ports and 2 SFP+ uplink ports, this Layer 2 managed switch supports a switching capacity of 80 Gbps and a forwarding rate of 58.72 Mpps—designed for data-intensive deployments such as blockchain node management, surveillance systems, and large-scale LANs.

Advanced networking features like link aggregation, IGMP snooping, camera recognition, and self-organizing network (SON) support ensure streamlined bandwidth distribution and enhanced device security. Cloud-based administration via Ruijie Cloud allows IT teams to monitor, configure, and scale infrastructure remotely, while tabletop or rack mounting flexibility simplifies installation in new builds or retrofits.

Key Features

8 x 10/100/1000Base-T Ethernet ports + 2 SFP+ uplink ports
80 Gbps switching capacity with 58.72 Mpps forwarding rate
Layer 2 architecture for high-speed local network traffic
Link aggregation support for improved redundancy and throughput
IGMP Snooping v1/v2 prevents unauthorized device access
Cloud management via Ruijie Cloud platform
SON (Self-Organizing Network) with IP, camera recognition supported
Security policy integration and ACL management
Supports 4094 VLANs, 16000 MAC address table entries

Technical Specifications

Performance & Networking

Layer Type: Layer 2
Switching Capacity: 80 Gbps
Forwarding Rate: 58.72 Mpps
Ports:

8 x 10/100/1000Base-T
2 x SFP+

MAC Address Table: 16000 entries
VLAN Capacity: 4094
Jumbo Frame Support (MTU): 9216 bytes
Link Aggregation Groups (LAG): 16
Access Control Lists (ACL): 1900

Security & Protocols

IGMP Snooping v1/v2: Supported
CPP (Control Plane Protection): Supported
EEE (Energy Efficient Ethernet): Supported
HTTP/HTTPS Access: Supported
Camera Recognition: Supported
Self-Organizing Network (SON): Supported

Power & Environmental

Rated Voltage Range: 100–240 V
Max Voltage Range: 90–264 V
Frequency: 50/60 Hz
Rated Current: 4.5 A
Fan Airflow Direction: Left-to-Right
Port Surge Protection: 6 kV
Operating Temperature: 0°C to 50°C (32°F to 122°F)

Physical & Warranty

Form Factor: Desktop / Rack-mountable
Dimensions: 300 mm x 233 mm x 43.6 mm (11.81 x 9.17 x 1.72 in)
Weight: 2.64 kg (5.82 lbs)
Warranty: 5-Year Manufacturer Warranty
